9VLR | pdb_00009vlr

Acinetobacter baumannii membrane-bound lytic transglycosylase B

PDB DOI: https://doi.org/10.2210/pdb9VLR/pdb

Classification: LYASE
Organism(s): Acinetobacter baumannii
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-06-26 Released: 2026-07-01
Deposition Author(s): Jang, H.S., Park, H.H.
Funding Organization(s): National Research Foundation (NRF, Korea)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.79 Å
R-Value Free:
0.205 (Depositor), 0.210 (DCC)
R-Value Work:
0.182 (Depositor), 0.188 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9VLR

This is version 1.0 of the entry. See complete history.

Literature

Acinetobacter baumannii membrane-bound lytic transglycosylase B

Jang, H.S., Park, H.H.

To be published.

Macromolecule Content

Total Structure Weight: 35.11 kDa
Atom Count: 2,687
Modeled Residue Count: 308
Deposited Residue Count: 315
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lytic murein transglycosylase B	A	315	Acinetobacter baumannii	Mutation(s): 0 Gene Names: mltB, EA722_03950
UniProt
Find proteins for A0A3R9RFD2 (Acinetobacter baumannii) Explore A0A3R9RFD2 Go to UniProtKB: A0A3R9RFD2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A3R9RFD2
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.79 Å
R-Value Free: 0.205 (Depositor), 0.210 (DCC)
R-Value Work: 0.182 (Depositor), 0.188 (DCC)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 75.49	α = 90
b = 75.49	β = 90
c = 175.36	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-01

Deposition Author(s):

Funding Organization	Location	Grant Number
National Research Foundation (NRF, Korea)	Korea, Republic Of	--

Revision History (Full details and data files)

Version 1.0: 2026-07-01
Type: Initial release
