9UPC | pdb_00009upc

Structure of human TREX-2

• PDB DOI: https://doi.org/10.2210/pdb9UPC/pdb
• EM Map EMD-64391: EMDB EMDataResource

• Classification: GENE REGULATION
• Organism(s): Homo sapiens
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2025-04-28 Released: 2026-02-11
• Deposition Author(s): Zhang, X., Gong, X., Ge, X.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.14 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Structure of human TREX-2

Zhang, X., Gong, X., Ge, X.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 109.35 kDa
• Atom Count: 6,159
• Modeled Residue Count: 759
• Deposited Residue Count: 959
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Germinal-center associated nuclear protein	A	463	Homo sapiens	Mutation(s): 0  Gene Names: MCM3AP, GANP, KIAA0572, MAP80 EC: 2.3.1.48 (PDB Primary Data), 2.3.1 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for O60318 (Homo sapiens) Explore O60318  Go to UniProtKB:  O60318
PHAROS:  O60318 GTEx:  ENSG00000160294

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
PCI domain-containing protein 2	B	426	Homo sapiens	Mutation(s): 0  Gene Names: PCID2, HT004
UniProt & NIH Common Fund Data Resources
Find proteins for Q5JVF3 (Homo sapiens) Explore Q5JVF3  Go to UniProtKB:  Q5JVF3
PHAROS:  Q5JVF3 GTEx:  ENSG00000126226

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
26S proteasome complex subunit SEM1	C	70	Homo sapiens	Mutation(s): 0  Gene Names: SEM1, C7orf76, DSS1, SHFDG1, SHFM1
UniProt & NIH Common Fund Data Resources
Find proteins for P60896 (Homo sapiens) Explore P60896  Go to UniProtKB:  P60896
PHAROS:  P60896 GTEx:  ENSG00000127922

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.14 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419:
RECONSTRUCTION	cryoSPARC	4.6

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2026-02-11
Deposition Author(s): Zhang, X., Gong, X., Ge, X.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32471302

Revision History

• Version 1.0: 2026-02-11
  Type: Initial release
