9JWT | pdb_00009jwt

De novo designed D-allose binding protein based on 1rpj

PDB DOI: https://doi.org/10.2210/pdb9JWT/pdb

Classification: DE NOVO PROTEIN
Organism(s): synthetic construct
Expression System: Escherichia coli B
Mutation(s): No

Deposited: 2024-10-10 Released: 2025-10-15
Deposition Author(s): Wang, X., Liu, Y.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.217 (Depositor), 0.217 (DCC)
R-Value Work:
0.185 (Depositor), 0.185 (DCC)
R-Value Observed:
0.187 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

De novo designed D-allose binding protein based on 1rpj

Wang, X., Liu, Y.

To be published.

Macromolecule Content

Total Structure Weight: 31.04 kDa
Atom Count: 2,428
Modeled Residue Count: 292
Deposited Residue Count: 296
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MSD3-holo	A	296	synthetic construct	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ALL (Subject of Investigation/LOI) Query on ALL Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	beta-D-allopyranose C₆ H₁₂ O₆ WQZGKKKJIJFFOK-QZABAPFNSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.217 (Depositor), 0.217 (DCC)
R-Value Work: 0.185 (Depositor), 0.185 (DCC)
R-Value Observed: 0.187 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.496	α = 90
b = 43.038	β = 90
c = 143.291	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-10-15

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-10-15
Type: Initial release
