1VRD | pdb_00001vrd

Crystal structure of Inosine-5'-monophosphate dehydrogenase (TM1347) from THERMOTOGA MARITIMA at 2.18 A resolution

• PDB DOI: https://doi.org/10.2210/pdb1VRD/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Thermotoga maritima MSB8
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2005-02-22 Released: 2005-03-15
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.18 Å
• R-Value Free:
  0.258 (Depositor), 0.260 (DCC)
• R-Value Work:
  0.217 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.219 (Depositor)

Starting Model: experimental

Literature

Crystal structure of Inosine-5'-monophosphate dehydrogenase (TM1347) from THERMOTOGA MARITIMA at 2.18 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C4  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA,PQS (software)

Biological Assembly 2

Global Symmetry: Cyclic - C4  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 2 assigned by authors and generated by PISA,PQS (software)

Macromolecule Content

• Total Structure Weight: 107.09 kDa
• Atom Count: 4,876
• Modeled Residue Count: 638
• Deposited Residue Count: 988
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
inosine-5'-monophosphate dehydrogenase	A, B	494	Thermotoga maritima MSB8	Mutation(s): 0  Gene Names: TM1347 EC: 1.1.1.205
UniProt
Find proteins for Q9X168 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9X168  Go to UniProtKB:  Q9X168

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.18 Å
• R-Value Free:  0.258 (Depositor), 0.260 (DCC)
• R-Value Work:  0.217 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.219 (Depositor)

Diffraction Data: https://doi.org/10.18430/M31VRD

Space Group: I 4

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 120.083	α = 90
b = 120.083	β = 90
c = 144.079	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MOLREP	phasing
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2005-03-15
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2005-03-15
  Type: Initial release

• Version 1.1: 2008-04-27
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Derived calculations, Source and taxonomy, Version format compliance
• Version 1.3: 2023-01-25
  Changes: Database references
• Version 1.4: 2023-09-20
  Changes: Data collection, Refinement description
